Chengdu Sheraton Hotel Lighting Project

Design story

From concept to delivered light

Project overview

A sophisticated hospitality lighting program for the Chengdu Sheraton Hotel, requiring uniform COB LED linear coves, precise CCT control at 3000K, CRI ≥90 color rendering, and maintenance-friendly concealed ceiling installations across guest rooms, corridors, lobby, and public dining zones. Mihoray supplied custom-length COB LED strips with matched aluminum profiles and DALI-compatible drivers.

Client needs

• Luxury hotel atmosphere with warm 3000K ambiance across guest journeys
• Dot-free, low-glare linear illumination for premium guest experience
• Soft, continuous linear illumination visible at close range in room coves
• Long-term operational stability for 16+ hours daily operation
• Dimming compatibility with existing DALI hotel control system
• Batch consistency across multiple floors and phases

Technical challenges

• Maintaining consistent light output and CCT uniformity across 8-12 meter continuous runs per room without visible brightness drop
• Achieving dot-free uniformity at close viewing distance (0.5-1.5m) in guest room ceiling coves
• Precise DALI dimming compatibility with the hotel's existing room management system without flicker at low levels
• Thermal management in concealed ceiling spaces with limited airflow to maintain LED lifespan
• Establishing a documented BOM that allows identical product re-ordering for future renovation phases

Mihoray solution

Project results

• Achieved uniform dot-free linear illumination across all guest floor coves and public circulation areas
• CCT consistency verified at ±30K across delivered batches — exceeding the ±50K specification
• Zero dimming compatibility issues reported during commissioning with existing DALI infrastructure
• Documented BOM with product codes, driver specs, and wiring diagrams archived for future phase procurement
• Energy consumption reduced by approximately 35% compared to the previous fluorescent installation

Project background

The Chengdu Sheraton Hotel, a premium international hospitality property in Sichuan Province, undertook a comprehensive lighting renovation program in 2024. The property required a complete upgrade of its linear cove lighting across guest rooms, corridors, lobby reception, executive lounge, and public dining areas. The existing fluorescent-based cove system showed color inconsistency, high maintenance burden, and incompatibility with the hotel's modernized DALI control infrastructure. The hotel's design consultant specified LED strip lighting with strict performance requirements: CRI ≥90 for accurate rendering of interior materials and guest skin tones, warm 3000K CCT for relaxation atmosphere, and dot-free uniformity suitable for the close viewing distances (0.5-1.5m) typical in guest room ceiling coves.

Design approach

Mihoray's engineering team proposed COB (Chip on Board) LED strip technology rather than conventional SMD strips based on the close viewing distance requirement. COB strips embed 512 LED chips per meter directly onto the PCB substrate, producing a continuous luminous surface without visible individual dots — essential for the premium aesthetic expected in international hotel properties. The system was designed on 24V architecture to support continuous runs of 8-12 meters per feed point, matching typical room perimeter lengths without requiring mid-run power injection. Each strip run terminates at an aluminum profile end cap with a waterproof connector for maintenance access. The aluminum profile design integrates a thermal management channel that keeps LED junction temperature below 65°C even in enclosed ceiling cavities, maintaining the rated 50,000-hour L70 lifespan under continuous evening operation.

Installation process

Installation followed a phased approach: first the aluminum profiles were mechanically fixed into ceiling cove recesses using spring clips at 500mm intervals. Wiring was pre-routed to driver locations accessible through maintenance panels in corridors. COB strips were then inserted into profiles and connected using tool-free plug connectors — allowing any future strip replacement without electrical work. Each floor was commissioned independently with DALI address assignment and scene programming. Mihoray provided pre-labeled strips and drivers with matching floor/zone codes to eliminate on-site confusion during installation.

Technical specifications

Product: COB LED Strip, 512 LEDs/m, 24V DC. Power: 14.4W/m. CCT: 3000K (±50K bin tolerance, achieved ±30K). CRI: ≥92 (Ra). IP Rating: IP20 (indoor). Maximum run: 10m single-end feed. Profile: Recessed aluminum, 18×12mm, with clip-in opal diffuser. Driver: Constant voltage 24V, DALI-2 compatible, flicker-free. Dimming range: 1%-100%. Lifespan: 50,000h L70 at Tc 65°C. Certifications: CE, RoHS.

Project outcome

The Chengdu Sheraton Hotel lighting renovation delivered a measurable improvement in guest environment quality while reducing maintenance burden and energy consumption. The property management reported zero lighting-related guest complaints in the six months following completion — compared to an average of 3-4 monthly complaints under the previous system. The documented BOM approach means the hotel can re-order exact replacement products for future renovation phases without re-specification. This project demonstrates Mihoray's capability to deliver batch-consistent, specification-grade LED strip lighting for international hospitality programs with complex control integration requirements.

Products used
